CuSn8 Bronze Bearings: VIIPLUS’s Durable, Self-Lubricating Solutions for Industrial Excellence
In the world of heavy-duty machinery and precision engineering, bronze bearings play a pivotal role in minimizing friction, enhancing longevity, and ensuring seamless operations. At VIIPLUS, we specialize in manufacturing premium wrapped perforated bronze bushings crafted from CuSn8 material—a high-performance tin-bronze alloy engineered to excel in demanding environments. Let’s explore why our bronze bearings are the go-to choice for industries worldwide.
**What Are CuSn8 Bronze Bushings?**
CuSn8 bronze bushings are cylindrical components made from a copper-tin alloy (CuSn8), comprising 7.5–8.5% tin, 0.01–0.4% phosphorus, and trace elements like iron, nickel, and zinc. The unique “wrapped perforated” design involves cold-forming a bronze strip into a cylindrical shape, creating a robust structure with diamond-shaped lubrication indents or perforations. These perforations act as reservoirs for grease or oil, enabling self-lubrication and reducing wear during operation.
Compliant with DIN 1494 standards, VIIPLUS’s bushings are precision-engineered for reliability, offering unmatched performance in high-load, low-speed, and corrosive environments.
**Why Choose VIIPLUS CuSn8 Bronze Bearings?**
-
Superior Material Properties
- CuSn8 Tin-Bronze Alloy: Renowned for exceptional wear resistance, high load capacity (up to 60 N/mm²), and resistance to fatigue and corrosion.
- Self-Lubricating Design: Diamond or round oil pockets retain lubrication, reducing friction and eliminating frequent maintenance.
-
Engineered for Versatility
- DIN 1494 Compliance: Guarantees dimensional accuracy and interchangeability.
- Customizable Sizes: Available in standard and custom dimensions (e.g., ID 65–80 mm, OD 70–85 mm, lengths up to 80 mm).
-
Cost-Effective Performance
- Wrapped Construction: More economical than solid bronze bushings, without compromising durability.
- Extended Service Life: Reduced downtime and replacement costs due to superior wear resistance.
-
Corrosion Resistance: Ideal for marine applications, agricultural machinery, and environments exposed to moisture or chemicals.
Applications of VIIPLUS Bronze Bearings
Our CuSn8 bronze bushings are trusted across industries for:
- Automotive Systems: Transmissions, steering columns, and suspension components.
- Industrial Machinery: Pumps, compressors, conveyors, and hydraulic systems.
- Agricultural Equipment: Harvesters, tractors, and tillage machinery.
- Marine Engineering: Ship engines, propeller shafts, and offshore equipment.
Product Spotlight: BRM10 Series Wrapped Bronze Bushings
The BRM10 metric standard bushings (DIN 1494) exemplify VIIPLUS’s commitment to quality:
- Material: CuSn8 alloy with cold-formed homogenous structure.
- Design: Diamond lubrication indents for optimal grease distribution.
- Variants: Plain cylindrical, flanged bearings, and grease reservoir models (e.g., F090 ID25 OD28).
Popular Sizes:
- ID 65 mm, OD 70 mm, L=40/60 mm
- ID 75 mm, OD 80 mm, L=80 mm
- ID 80 mm, OD 85 mm, L=60 mm
Advantages Over Competitors
- Precision Manufacturing: Tight tolerances ensure perfect fitment.
- Reduced Maintenance: Self-lubricating design minimizes manual greasing.
- Global Standards: Compliant with DIN, ISO, and international specifications.
**Why Partner With VIIPLUS?**
At VIIPLUS, we combine cutting-edge metallurgy with decades of expertise to deliver unbeatable bronze bearing solutions. Whether you need standard DIN-compliant bushings or custom-engineered sleeves, our team provides:
- Technical Support: Guidance on material selection, lubrication, and installation.
- Rapid Delivery: Global shipping for urgent requirements.
- Quality Assurance: Rigorous testing for performance and longevity.
Upgrade Your Machinery with VIIPLUS CuSn8 Bronze Bushings
From heavy industrial loads to corrosive marine settings, VIIPLUS’s wrapped perforated bronze bearings ensure smooth, efficient, and long-lasting performance. Explore our BRM10 series or request custom dimensions today!
Contact VIIPLUS for specifications, pricing, or application support. Let’s engineer success together!
Meta Description: Discover VIIPLUS’s CuSn8 bronze bearings—self-lubricating, DIN 1494 compliant, and built for high-load applications. Explore BRM10 series specs, sizes, and industrial benefits.
Keywords: CuSn8 bronze bushing, wrapped perforated bronze bearing, DIN 1494 standard, self-lubricating bearings, VIIPLUS bronze bushings, BRM10 series, bronze sleeve dimensions.
Optimized for SEO with keyword-rich headings, structured data, and actionable CTAs. Enhances VIIPLUS’s authority in bronze bearing solutions while addressing user intent for technical specifications and industrial applications.
Chemical Composition:
| Type | Cu% | Sn% | P% | Pb% | Zn% |
| TSB--090 | 91.3 | 8.5 | 0.2 | / | / |
Tech. Data:
| Max.Load (Static) | 120N/mm² |
| Max.Load (Dynamic) | 40N/mm² |
| Max.Speed (Lubrication) | 2m/s |
| Max.PV | 2.8N/mm²*m/s |
| Tensile strength | 450N/mm² |
| Hardness | HB 110-150 |
| Elongation | 40% |
| Temperature | -100℃~+200℃ |
| Friction coefficient | 0.08-0.25 |
| Thermal conductivity | 58W(m*k)-1 |
| Coef. of thermal expansion | 18.5*10-6*K-1 |
Applications:
This wrapped bronze bushing is widely used in construction engineering machinery, automotive industry, tractors, trucks, agriculture machinery and mining machines. The available products include bushings, bearing shelves, flanged bushings and thrust washers.
Premium Bronze Bushings, CuSn8 Bronze Gleitalger, Large Range Of Sizes, View Our Catalog Get Our Catalog & Find Information.
On Sizes, Prices & Availability! Click To See Over 200 Sizes Of Sleeved & Flanged Bearings!You have access to the latest downloads here. Click on the Wrapped Bronze Bushings.pdf catalog symbol to display the file, and download the self-lubricating bushing bearings catalog file.
Bronze Wrapped Bushing & Cylindrical Flange Bushes Made In China
bronze bushing stock
bronze bushings catalog
metric bronze bushings
Find a Bronze Lube Bushing, All solid bronze bearings can be prepared to meet your needs for ID, OD, length, shape, and size. Tin bronze bushings cusn8/cusn6 Manufacturer made-to-order from china Metallic Bushing Series.bronze bearings china sourcing:https://viiplus.com;Designed to handle high torque loads. Lubrication maintenance is required. Cylindrical, flanged, and thrust bushings forms are available. Find the 090 Cylindrical bearing Nominal Diameter Part Number ID OD Width.VIIPLUS Brass bushings are manufactured using an upgraded alloy when compared to OEM alloy bushings. The high-quality bushings increases wear properties while maintaining excellent metal lubricity. VIIPLUS tin bronze bushings are specifically designed to prevent galling and decrease wear.
Slide Bearings Customized Manufacturing Cusn8/Cusn6.5 /Bronze Plain Bearings With Grease Reservoirs
Bronze Wrapped bearings Shapes & forms Plain cylindrical bearings, flanged bearings, thrust washers, sliding plates.
Bearing material made of the solid bronze strip with indents for lubrication Maintenance-free bearing for general engineering applications:
Mining & Earthmoving Bearings Products
Custom & Oilfield Manufacturing Bronze Bearings
Optimum performance under relatively light loads and high speeds
Produced by powder metallurgy process and therefore suitable for complex shapes
Wide range of parts available from stock
Application: Forest- and constructional machinery, agricultural machinery, cranes, forklifts, hoisting equipment, etc.
F090-Straight F090-Flange
Product Description
Bushings Plain Bearings and Sleeve Bearings
CUSN8/6.5 is made from high-grade phosphorous tin bronze alloyed bushings. The slide bearings are specially designed to withstand heavy loads and to be shock-resistant. The entire bearing sliding surface consists of lubrication pockets that build up a lubricating film that reduces friction, both at startup and during operation. CUSN8/6.5 BRONZE is intended for radial, oscillating and axial movements and are especially suited for extra high loads. Bronze Bushings take over where other types of bearings break or fail.
090 Wrapped Flange & Straight Bronze Bearing With Lubrication Indents
| Wrapped bushing, Bronze CuSn8, DIN 1494 / ISO 3547, Low-maintenance |
| TECHNICAL DETAILS |
| Specific load capacity static | < 120 [N/mm2] | Temperature strain | - 40 [°C] to + 250 [°C] |
| Specific load capacity dynamic | < 40 [N/mm2] |
| Sliding speed | ≤ 2.5 [m/s] | Max. PV-value | 2.8 [N/mm² x m/s] |
| Friction value | 0.05 [µ] to 0.12 [µ] depending on lubrication | The percentage of contact area on the ID | > 75 [%] |
| MATERIALS |
| Support material | CuSn8P (DIN 17662) | alternative CuSn6P available |
| TOLERANCE DETAILS |
| Housing Ø | H7 | Shaft tolerance | f7 to h8 |
| Bushing inner-Ø after mounting | H9 |
| SHAFT MATERIAL |
| Steel, hardened or untempered |
| The surface roughness ≤ Ra 0.8 |
| PROPERTIES |
| Economic solution for bronze bearing application due to a thin wall thickness. High load capability and good stability with low abrasion. Suitable for rough working conditions, good corrosion resistance. |
| RANGE OF APPLICATION |
| Agriculture machinery, truck cranes & construction machinery, suitable for impact loads |
| MAINTENANCE |
| It is a low maintenance bushing material. An initial greasing during installation is necessary, after that periodic greasing with oil or grease is mandatory. The diamond pockets are an excellent lubrication depot and keeping maintenance to a minimum. |
| MOUNTING ADVISE |
| Housing | Chamfer min. 1.5 mm x 15-45°, for easy bushing alignment |
| Shaft | Chamfer 5 mm x 15°, for easy insertion of the shaft |
| We advise using a force-fitting mandrel for the installation of the bushing. It might be necessary to apply some grease on the outer surface of the bushing when press fitting it into the housing. |
| Gluing | Adhesive should not contact the sliding surface! |
Characteristics:
CuSn8/CuSn6.5 090 CYLINDRICAL BUSHES FLANGE BUSHES
Bronze Bearing Factory, Bronze Bushing supplier, CuSn8 flange bronze bush.Bearing material made of the solid bronze strip with indents for lubrication
Good wear resistance, suitable for rough conditions
Optimum performance under relatively high loads and low speeds
1.Easy for fitting and lubricating
2.High load capacity
3.Inner Diameter machineable parts are available against order
4.High level thermal conductivity
5.Minimum overall dimensions
6.Chemical resistance.
7. Initial pre-lubrication at assembly required...
Good performance in lubricated applications/Very Good performance in greased applications/Suitable for linear, oscillating and rotating movements/Bronze Wrapped Bearings offer good wear and low friction performance over a wide range of loads, speeds, and temperatures.
Bronze self-lubricating bearings used a kind of high-density bronze alloy of special compositions as the base, the surface of the alloy is rolled diamond type of the oil indents or half ball oil indents, this kind of bearing has higher density, load capacity, well-wearing performance, longer lifetime. It has been widely used in many fields, such as hoist machines, building machinery, machine tool industry, and mining machinery.
CuSn6 / CuSn8 Phosphor Tin Bronze Bushings Sliding Bearing
Phosphor bronze is characterized as a very pure alloy with extremely low content of impurities. Phosphor blends well with copper making the material hardly reacting on oxygen (oxidation).
Phosphor bronze is an alloy with high wear resistance and good mechanical properties. There are tubes, bars, and plates of different thicknesses available in phosphor tin bronze.
CuSn8 with Lubrication 090 Flange Bushes Bronze Bearings made of CuSn8/6.5 with Lubrication Indents high precision oil less bronze bearings.
Wrapped Bronze Bearings (low-maintenance), used for heavy load applications, offered with lubrication pockets, grooves or thru-holes, plain or flanged bearings, and strip
Bronze Wrapped Bearing with Oil Pockets(090 CYLINDRICAL BUSHES)
Sliding Bearing 090 caused by chemicals and environments. During the operation, the grease & oil will be released from the Indentations, which allow for long-term lubrication. Compare with Machined bronze bearings; 090 can offer some advantages including thin wall, lower weight, cheaper cost, high load etc. It is suitable for high load, lower speed application like construction, Transport, and agriculture machinery.
The bearings are wrapped from a cold-formed homogenous bronze (CuSn8) with exceptional material properties. The standard sizes are fitted with diamond-shaped lubrication indents in the bearing surface. These indents serve as lubricant reservoirs to rapidly build up a lubrication film at the start of the movement and thereafter reduce the running friction. The material is suitable for construction and agricultural machinery applications. Bronze Bearings and Bronze Sleeve Bushings made of CuSn8 with Lubrication Indents. We provide a professional sliding bearing solution
Data Parameter
| Performance indicators | Date |
| Maximum load | Static load | 120N/mm² |
| Dynamic load | 40N/mm² |
| Maximum linear velocity | 2.5m/s |
| High PV value | 2.8N/mm²・m/s |
| Coefficient of friction | 0.08~0.25 |
| The use of temperature | -100℃~+200℃ |
| Coefficient of thermal conductivity | 60W/m・K |
| Coefficient of thermal expansion | 15×-6/K |
Standard Dia. |
O.D.Size |
Housing Bore |
I.D.Size |
Matching Shaft Diameter |
| 10~18 | +0.065
+0.030 | +0.018
0 | +0.046
0 | - 0.016
- 0.043 |
| 18~30 | +0.075
+0.035 | +0.021
0 | +0.052
0 | - 0.020
- 0.020 |
| 30~50 | +0.085
+0.045 | +0.025
0 | +0.062
0 | - 0.025
- 0.064 |
| 50~80 | +0.100
+0.055 | +0.030
0 | +0.074
0 | - 0.030
- 0.076 |
| 80~120 | +0.120
+0.070 | +0.035
0 | +0.087
0 | - 0.036
- 0.090 |
| 120~180 | +0.170
+0.100 | +0.400
0 | +0.100
0 | - 0.043
- 0.106 |
| 180~250 | +0.210
+0.130 | +0.046
0 | +0.115
0 | - 0.050
- 0.122 |
| 250~315 | +0.260
+0.170 | +0.052
0 | +0.130
0 | - 0.056
- 0.137 |
Bearing forms available in standard dimensions: Cylindrical bushes/Bearing forms made to order: cylindrical bushes with non-standard dimensions, flanged bushes, sliding plates, customized bearing designs
Typical Applications
This type of bushing is widely applied in hoisting machines and other construction machines, automobiles, tractors, trucks, machine tools, and some mineral engines. It can be fabricated into bushes, half bearings, flanged bushes, thrust washers, spherical bearing, and soon.
